Stainless Steel Pipe fittings (as opposed to Tube fittings) are a butt weld fitting for direct welding onto pipe. This allows them to be fitted with specific process connections such as the sanitary fittings detailed above. The Dixon brand has a similar product range of hygienic butterfly valves and check valves.Īll end connections are standard tube butt-weld. The Keystone F264J Check Valve is a hygienic one way / Non Return Valve. Hygienic Keystone F250 Butterfly valves are used throughout the food and beverage industry as an isolation or ‘modulating’ valve. Blank caps and blank nuts are available to blank off the males at the end of a line.

A robust plastic wing nut is available in 2” only. The wine nuts are available in stainless steel wing and slotted configurations. The brass wing nuts are unique to this union. Wine Unions – originated in Australia for the wine industry, and consist of a Wine male, liner, seal and nut.for the Australian Standard and B.S for the British Standard, this is the German Standards institute prefix. The acronym D.I.N translates from German as Deutsche Industrie Normale. Australia is seeing an increase in the use of DIN fittings as more equipment is imported from Germany.

They typically have a D profile EPDM seal and a four slot nut.

DIN Unions – A DIN union comprises a male, nut, seal and liner.

There are many different seal materials, including EPDM, Silicon, Teflon, Viton & Buna. Triclover Blank caps are used to blank off a ferrule at the end of a line. They have 2 body halves (Triclover ferrules) which have a butt-weld end to suit tube, and a face side which accommodates a seal and is then brought together with a finger nut clamp.

Triclover Unions – or Tri Clamp Unions or Ferrule Fittings are referred to as a sanitary fitting due to their clean nature and lack of thread.

BSM blank caps and BSM blank nuts are available to blank off a male at the end a of line. The unit is tightened with a special BSM spanner. The hexagon nut holds the male with the O ring and liner together. These consist of a BSM Male, Liner, Nut and O-Ring. Below are some of the more common fittings used in Australia.īSM Unions– BSM stands for British Standard Milk (originating from the milk industry). There are many types of stainless steel sanitary / hygienic fittings.

Couplings (or sockets, but referred to as couplings in NPT as the internal thread is not continuous throughout the fitting).

Cross Over Nipples (NPT to BSP male adaptors).

The NPT Pipe Fittings generally stocked are 3000 lb high pressure.ģ16 stainless steel NPT fittings include: Also the male and female fittings are tapered to prevent the different threads being readily interchangeable. NPT pipe fittings are similar to BSP but with a 5 degree difference in the thread angle. NPT is short for National Pipe Thread / Taper an American standard for pipe threads.

There are many fittings available and here is a list of commonly stocked items: When these two thread forms are screwed together with thread tape as a sealant they will bind and seal across only one or two threads for a leak proof connection. Also known as a G thread) female fittings. Also known as an R thread) male fittings and BSPP (parallel. Commonly stocked stainless steel BSP Fittingsare BSPT (tapered. Stainless Steel BSP FittingsīSP is an acronym for British Standard Pipe and is a common pipe thread in Australia. Detailed below are several types of stainless steel fittings.
